Item # : KWVE25BHG2V1
Series: KWVE-BH series
Block Type: Square block
Model Size : 25mm
Load Type: Medium Load
Block Mounting: Mounting from Top
Block: standard carriage, four-row, full complement ball set
Distance from the Edge: Tolerance of E value for standard rail is ± 0.5mm.
Preload Class: V1 (0.04 C), V2 (0.1 C)
Four-row linear recirculating ball bearing and guideway assemblies represent the most extensive and complex group within the range of monorail guidance systems. They are used where linear guidance systems with high load carrying capacity and rigidity must move heavy loads with high running and positional accuracy as well as low friction. The guidance systems are preloaded and are suitable for long, unlimited stroke lengths.
Depending on the operating conditions, accelerations up to 150 m/s2 and speeds up to 360 m/min are possible. Where designs are planned with extensive use of accessories and travel speeds >180 m/min, please contact us.
The units are available in full complement design and with QuadSpacers. A guidance system comprises at least one carriage with rolling elements, a guideway and two-piece plastic closing plugs. The four-row linear recirculating ball bearing and guideway assemblies are supplied with initial greasing as standard.
Four-row linear recirculating ball bearing and guideway assemblies are linear guidance systems of X-life quality. They are characterised by improved technological characteristics, increased robustness and a longer operating life.
|Block Type||Square type|
|Model Size ||25 mm|
|Load Type||V2 (0.1C)|
|Block Mounting||Mounting from Top|
|Block||standard carriage, four-row, full complement ball set|
V1- Light Preload (0.04C) ,
V2-Heavy Preload (0.1C)
Standard preotection (End seal and bottom seal
Single color box of original
Suitable carton size
Carton box for rail
For the large quantity of the rail or linear carriage, We will package them with wooden box before shipment.
Any questions and answers for INA linear guides
|2. ||Fake or original genuine INA products you supply to customer?||We provide the products.|
|3.||How to gurantee of original INA brand?|
|4. ||What kind of INA linear guide you can supply to customers?||We can supply KWVE-B, KWVE-BH, KWVE-BHL, KWVE-BS, RWU-EG, RWU-EH,RWU-EHL types etc.|
|5.||What length of linear rail you provide to customers?|
Max length of linear rail is 5600mm each, we can cut linear rail length by customer's
also supply the joint service if needs 1 pcs more than 5600mm.
|6.||What preload of INA linear guide you supply to customers?||V0, V1, V2, ( contact sales to get the details)|
|7.||What accuracy of INA linear guide you can supply to customers?|
Grade G3,G2,G1 ( Stocked items)
|8.||Do you have stock for precision roller guides?||Yes, we have stocked of RWU roller guides, ( has square and Flange type)|
|9.||Can you supply dust seals and self- lubricating systems of linear block?||Yes, ZZ, KK, DD, SH, ZH, DH, KH dust seals and E2 self-lubricating systesm all is available. |
|10.||Can you sell the linear block and linear rail in separated?||Sure, Linear block and linear rail in separated is available. |
