CPC ARC Type Linear Guideway ARC45ML ARC45

Item # : ARC45ML
Series: ARC series
Block Type: Square block
Model Size : 45mm
Load Type: Light Load
Block Mounting: Mounting from Top
Block: Ball type block
Distance from the Edge: Tolerance of E value for standard rail is ± 0.5mm.
Preload Class: V0- Light Preload (0.02C) , V1- Medium Preload (0.05C) , V2-Heavy Preload (0.08C)
Quantity:
  • ARC45ML, ARC 45 ML
  • CPC
  • ARC45MLBV0N

The CPC ARC/HRC/ERC Linear Guide Series uses the O-type arrangement for the four row ball circulation design. The contact angle between the rail and ball is 45 degrees, and can realize the 4 directional load  effects. CPC places special emphasis on strengthening the Arm length(LO), so when sustaining external  force F, will have even higher Mr value to increase the rigidity and static moment capability.  In addition, the runner block for the same size uses larger and more balls, so will outperform  competitor’s models by 10% to 30% regarding load capabilities. The products have characteristics  of high load, high moment, and high stiffness.


Please notat that the first hole of rails (E dimensions will be the same at both ends unless otherwise specified in the purchase order). Also for the rails accuracy we have C (Normal), H (high), P(High precision) in stock, for the accuracy details, please kindly check within next page of Pdf file (G-Interchangeable-Accuracy-Grade).

CPC LINEAR GUIDE

CPC product design

Item #

ARC45ML, ARC 45 ML

Series
ARC series
Block Type
Square type
Model Size
45 mm
Load Type
Light load of V0
Block Mounting
Mounting from Top
Block
Standard type block

Preload Class

V0- Light Preload (0.02C)  ,

V1- Medium Preload (0.05C) ,

V2- Heavy Preload (0.08C)


Precision code

N (normall)

Dust Protection

Standard preotection (End seal and bottom seal


AR HR LINEAR GUIDE ACCURACYAR HR LINEAR GUIDE PRELOAD
